Microair Avionics T3000BNX2D Skysuite Navigation Sensors With Battery Backup

0 Reviews 0 Answered Questions
Select Version:
T2000ADSB Out Upgrade From SFLT2000ADSB IO Upgrade From SFLT2000ADSB IO Upgrade From ADSB Out
Price Includes GST
Quantity
Add to Wishlist

Overview

T2000ADSB-Out Transponder – Upgrade (From T2000SFL)
Economical upgrade to ADSB Out for owners of Microair T2000SFL Transponder. Enhanced visibility – to both other aircraft and Air Traffic Control Compact design in one unit – enables simple ready to go, plug and play installation.
Seamless integration of GPS position source and altitude encoder – no further configuration or purchases required.
Ideal for light sport and experimental aircraft operators looking for enhanced visibility and to meet airspace mandates, the new Microair ADSB Transponder integrates Mode AC, ADSB out, GPS position source and altitude encoder in one compact unit.
Designed for easy installation, the ADSB Transponder improves situational awareness by making you visible to other aircraft.

T2000ADSB-IO Transponder – Upgrade
Provides a stream of traffic data to your Android Tablet or IPAD and to your favourite App that supports GDL90 traffic, to improve your situational awareness Economical upgrade to ADSB-IO for owners of Microair T2000 Transponder. Enhanced visibility – to both other aircraft and Air Traffic Control Compact design in one unit – enables simple ready to go, plug and play installation Seamless integration of GPS position source and altitude encoder – no further configuration or purchases required.
ADSB-In provides a stream of traffic data to your Android Tablet or Ipad and to your favourite App that supports GDL90 traffic, including AvPlan*, OzRunways* and ForeFlight* to improve your situational awareness (*Trademarks of their respective companies, Apps available for purchase).
Ideal for light sport and experimental aircraft operators looking for enhanced visibility and to meet airspace mandates, the new Microair ADSB Transponder integrates Mode AC, ADSB In and Out, GPS position source and altitude encoder in one compact unit.

T2000ADSB-Out Transponder
The T2000ADSB Out Transponder- the perfect upgrade for increased aircraft awareness and safety. Fitting your existing 2.25″ panel slot, easily install this robust Mode A & C transponder with ADSB capability and make sure you’re seen with ADSB technology.
Enhanced visibility – to both other aircraft and Air Traffic Control Compact design in one unit – enables simple ready to go, plug and play installation.
Seamless integration of GPS position source and altitude encoder – no further configuration or purchases required.
Ideal for light sport and experimental aircraft operators looking for enhanced visibility and to meet airspace mandates, the new Microair ADSB Transponder integrates Mode AC, ADSB out, GPS position source and altitude encoder in one compact unit.
Designed for easy installation, the ADSB Transponder improves situational awareness by making you visible to other aircraft.

Specifications

  • Weight: 0.6 kg
  • Dimensions: 16 ื 6.1 ื 6.1 cm
  • Mounting: Round panel mount 2 ผ” (57 mm)
  • Control Backlit: LCD with rotary selector for setting Mode A code, Flight ID and settings. Push buttons for easy access to common features such as Ident and VFR default code.
  • Temperature: -20 to +55 Celsius
  • Altitude: 55,000 feet, inbuilt altimeter to 30,000 feet
  • Power Input: 10 to 33 volts DC negative chassis ground, 2W average (7W peak)
  • RF Output: 1090 Mhz at 200 watts (nominal peak power)
  • SWR Tolerance: <5:1 or open feed line
  • Options: Wiring harness available
  • Accompanying App:
  • • iOS and Android T2000 App
  • • Allows configuration and settings from an intuitive app installed on the owner’s or pilot’s personal device
  • • Secondary display of altimetry and position data
  • • Facilitates periodic software updates as new features and functions are released
